Cmos Voltage References - An Analytical and Practical Perspective

Informationen zum Autor Chi-Wah Kok, Canaan Microelectronics Corporation Limited, China Chi-Wah Kok obtained his degree from the University of Wisconsin Madison. Since 1992, he has been working with various semi-conductor companies, research institutions and universities, which include AT&T Labs Research, Holmdel, SONY U.S. Research Labs, Stanford University, Hong Kong University of Science and Technology, Hong Kong Polytechnic University, City University of Hong Kong, and Lattice Semiconductor. In 2006, he founded Canaan Microelectronics Corp Ltd., a fabless IC company with products in mixed signal IC for consumer electronics. He has extensively applied signal processing techniques to improve the circuit topologies, designs, and fabrication technologies within Canaan. This includes the application of semidefinite programming to circuit design optimization, abstract algebra in switched capacitor circuit topologies improvement, and nonlinear optimization methods to optimize high voltage MOSFET layout and fabrication. Wing-Shan Tam, Canaan Microelectronics Corp Limited, China Wing-Shan Tam received her BEng degree in electronic engineering from The Chinese University of Hong Kong, and MSc degree in electronic and information engineering from The Hong Kong Polytechnic University, and PhD degree in electronic engineering from the City University of Hong Kong in 2004, 2007, and 2010, respectively. Currently, she is the Engineering Manager of Canaan Microelectronics Corp Ltd., and she has been working with CMOS circuit design since 2004. Her research interests include mixed-signal integrated circuit design for data conversion and power-management. Klappentext A practical overview of CMOS circuit design, this book covers the technology, analysis, and design techniques of voltage reference circuits. The design requirements covered follow modern CMOS processes, with an emphasis on low power, low voltage, and low temperature coefficient voltage reference design. Dedicating a chapter to each stage of the design process, the authors have organized the content to give readers the tools they need to implement the technologies themselves. Readers will gain an understanding of device characteristics, the practical considerations behind circuit topology, and potential problems with each type of circuit.Many design examples are used throughout, most of which have been tested with silicon implementation or employed in real-world products. This ensures that the material presented relevant to both students studying the topic as well as readers requiring a practical viewpoint.* Covers CMOS voltage reference circuit design, from the basics through to advanced topics* Provides an overview of basic device physics and different building blocks of voltage reference designs* Features real-world examples based on actual silicon implementation* Includes analytical exercises, simulation exercises, and silicon layout exercises, giving readers guidance and design layout experience for voltage reference circuits* Solution manual available to instructors from the book's companion websiteThis book is highly useful for graduate students in VLSI design, as well as practicing analog engineers and IC design professionals. Advanced undergraduates preparing for further study in VLSI will also find this book a helpful companion text. Zusammenfassung A practical overview of CMOS circuit design, this book covers the technology, analysis, and design techniques of voltage reference circuits. The design requirements covered follow modern CMOS processes, with an emphasis on low power, low voltage, and low temperature coefficient voltage reference design. Inhaltsverzeichnis About the Authors ix Preface xi Acknowledgements xiii Nomenclature xv 1 Warm Up 1 1.1 Bipolar Junction Transistors 2 1.1.1 Differential VBE 5 1.2 Metal-Oxide Sem...

Table des matières

About the Authors ix

Preface xi

Acknowledgements xiii

Nomenclature xv

1 Warm Up 1

1.1 Bipolar Junction Transistors 2

1.1.1 Differential VBE 5

1.2 Metal-Oxide Semiconductor Field-Effect Transistor 7

1.2.1 Cutoff Region 11

1.2.2 Subthreshold Conduction 11

1.2.3 Triode Region 14

1.2.4 Saturation Region 16

1.2.5 Thermal Properties 19

1.2.6 Channel Length Modulation Effect 23

1.3 Diode 23

1.4 Resistor 25

1.4.1 Dummy Element 27

1.4.2 Guard Ring 27

1.4.3 Sheet Resistance 27

1.5 Device Matching 28

1.5.1 Application of Statistics to Circuit Design 28

1.5.2 Systematic Variation 30

1.6 Simulation Models for Circuit Design 31

1.6.1 Process Variation and Typical Design 32

1.6.2 Process Corners 34

1.7 Noise 36

1.7.1 Types of Noises 36

1.7.2 Sums and Multiplications of Noises 38

1.8 Fabrication Technology 39

1.9 Book Organization 40

1.10 Exercises 42

References 46

2 Voltage Reference 49

2.1 Performance Measures 49

2.1.1 Line Regulation 51

2.1.2 Temperature Coefficient 54

2.1.3 Power Supply Rejection Ratio 56

2.1.4 Quiescent Current 59

2.1.5 Output Noise 60

2.2 Other Design Considerations 62

2.3 Summary 63

2.4 Exercises 65

References 70

3 Bandgap Voltage Reference 71

3.1 Widlar Bandgap Voltage Reference Circuit 71

3.2 Drain Voltage Equalization Current Mirror 74

3.2.1 Opamp Based

ß-Multiplier Bandgap Voltage Reference Circuit 76

3.2.2 Bandgap Voltage Reference Circuit 77

3.3 Major Circuit Elements 81

3.3.1 Operational Amplifier 81

3.3.2 Current Mirror 86

3.3.3 Startup Circuit 88

3.3.4 Resistor Network 93

3.3.5 Bipolar Transistor 94

3.4 Complete Layout 95

3.5 Summary 95

3.6 Exercises 96

References 101

4 Error Sources in Bandgap Voltage Reference Circuit 103

4.1 Non-Ideal Opamp 103

4.1.1 Input Offset Voltage 104

4.1.2 Limited Gain and Power Supply Rejection Ratio 112

4.1.3 Noise 113

4.2 Current Mirror Mismatch 114

4.2.1 Channel Length Modulation Effect Compensation 116

4.2.2 Cascode Current Mirror 117

4.3 Bipolar Transistor 122

4.3.1 Size Variation 122

4.3.2 Series Base Resistance 122

4.3.3 ß Variation 125

4.4 Resistor Variation 126

4.5 Power Supply Variation 127

4.5.1 Pre-Regulation 132

4.6 Output Loading 135

4.7 Output Noise 138

4.8 Voltage Reference Circuit Trimming 140

4.8.1 Linked Fuse Resistor Trimming 141

4.8.2 Resistor Trimming Circuit Analysis 142

4.8.3 Modulated Trimming 146

4.8.4 Voltage Domain Trimming 148

4.8.5 Current Domain Trimming 149

4.9 Summary 149

4.10 Exercises 151

References 161

ADVANCED VOLTAGE REFERENCE CIRCUITS

5 Temperature Compensation Techniques 165

5.1 VBE . DeltaVBE Compensation 166

5.1.1 Brokaw Bandgap Voltage Reference 168

5.1.2 ß-Multiplier VBE . DeltaVBE Compensation 170

5.2 Widlar PTAT Current Source and VBE Compensation 175

5.3 VGS Based Temperature Compensation 177

5.3.1 VGS Current Source 178

5.4 Summary 182


Détails du produit

• Auteurs: Kok, Chi-Wa Kok, Chi-Wah Kok, Chi-Wah (Canaan Microelectronics Kok, Chi-Wah Tam Kok, Chi-wah/ Tam Kok, Cw Kok, Kok Chi-Wah, Wing-Shan Tam, Tam Wing-Shan
