Schlieren and Shadowgraph Methods in Heat and Mass Transfer

Schlieren and Shadowgraph Methods in Heat and Mass Transfer lays out the fundamentals of refractive index based imaging techniques, optical configurations, image analysis, and three dimensional reconstructions. The present monograph aims at temperature and concentration measurements in transparent media using ray bending effects in a variable refractive index field. Data analysis procedure for three-dimensional reconstruction of temperature and concentration field using images at different view angles is presented. Test cases illustrating the validation of the quantitative analysis procedure are presented.

Sommario

Optical Methods - an Overview.- Laser Schlieren and Shadowgraph.- Rainbow Schlieren.- Principles of Tomography.- Validation Studies.- Closure.

Info autore

Pradipta Kumar Panigrahi, Indian Institute of Technology Kanpur, [e-mail]
Krishnamurthy Muralidhar,  Indian Institute of Technology Kanpur, [e-mail]

Riassunto

Schlieren and Shadowgraph Methods in Heat and Mass Transfer lays out the fundamentals of refractive index based imaging techniques, optical configurations, image analysis, and three dimensional reconstructions. The present monograph aims at temperature and concentration measurements in transparent media using ray bending effects in a variable refractive index field. Data analysis procedure for three-dimensional reconstruction of temperature and concentration field using images at different view angles is presented. Test cases illustrating the validation of the quantitative analysis procedure are presented.

Dettagli sul prodotto

• Autori: muralidhar krishnamurthy, Krishnamurth Muralidhar, Krishnamurthy Muralidhar, Pradipta K. Panigrahi, Pradipta Kuma Panigrahi, Pradipta Kumar Panigrahi
• Editore: Springer, Berlin
• Lingue: Inglese
• Formato: Tascabile
• Pubblicazione: 14.05.2012
• EAN: 9781461445340
• ISBN: 978-1-4614-4534-0
• Pagine: 128
• Peso: 230 g
• Illustrazioni: XI, 128 p. 69 illus., 17 illus. in color.
• Serie: SpringerBriefs in Applied Sciences and Technology; SpringerBriefs in Thermal Engineering and Applied Science; SpringerBriefs in Applied Sciences and Technology; SpringerBriefs in Thermal Engineering and Applied Science
• Categoria: Scienze naturali, medicina, informatica, tecnica > Tecnica > Meccanica, tecnica di produzione
