Dvb-H Handbook - The Functioning and Planning of Mobile TV

A guide to implementing the DVB-H system for the carriage of MobileTV services, The DVB-H Handbook provides an overview of all aspects of the specification. Placing particular emphasis on the technical elements, it includes important information on the signalling and service discovery. The background, functioning, planning and optimisation of DVB-H are systematically explained for use in network planning and optimization. Subjects such as coding, different modes for channel delivery and protection in core and radio system are detailed. Giving examples on the practical interpretation of the DVB-H specifications, this book also describes the process behind the realization of the end-to-end system.

* Outlines the functioning, planning and optimization of the complete DVB-H system

* Spans topics from physical network planning and link layer specifications, to application ingredients such as EPGs and audiovisual streaming technologies

* Uses illustrations and selected case examples reflecting real-life practice to give greater understanding

* Functions as an overview of the topic, as well as a tutorial for implementing the system

* A must-read for beginners as well as established experts within the field of Mobile broadcasting

List of contents

1 General

1.1 Setting up the scene

1.2 Benefits of DVB-H

1.3 Standardization

1.4 Contents of the book


2 DVB-H overview

2.1 Time Slicing

2.1 MPE-FEC

2.2 DVB-H specific signaling

2.3 The broadcast and cellular systems in DVB-H

2.4 Market needs

2.5 Applications

2.6 Mobile TV Business Eco-System

2.7 The Network of Dependencies in Mobile TV Business

2.8 Mobile TV Business Roles

2.9 Vertical Business Model, Mobile Operator Driven Model

2.10 Virtual Network Operator Model, Mobile Operator Driven Model

2.11 Wholesaler - Reseller Model, Broadcast Network Operator Driven Model

2.12 NewCo or Consortium - Broadcaster Driven Model

2.13 Revenue Models

2.14 Broadcast Network as starting point


3 Technical architecture

3.1 Main elements

3.2 Core network

3.3 Mobile Broadcast Solution (MBS)

3.4 Radio network

3.5 Interfaces and protocols


4 DVB-H Equipment

4.1 Terminals

4.2 Core Elements

4.3 Radio elements

4.4 Antenna systems

4.5 Measurement equipment

4.6 Other equipment


5 Functionality of the system

5.1 The protocol stack of the end-to-end OMA-BCAST over DVB-H system

5.2 The upper layer protocols

5.3 MPE in DVB-H

5.4 MPE-FEC frame

5.5 The principle of time-sliced transmission

5.6 Program Specific Information (PSI)/Service Information (SI)

5.7 Transport Stream

5.8 Transmission Parameter Signaling (TPS)

5.9 The head-end functionality

5.10 The receiver and terminal functionality

5.11 The DVB-H network types


6 Signalling

6.1 Service Discovery Signalling

6.2 End-to-End Service Discovery

6.3 Interaction channel

6.4 Service and Content Protection


7 DVB-H Head-End

7.1 Overview

7.2 A/V Content Encoding

7.3 A/V Content Scrambling

7.4 ESG Generation

7.5 IP Encapsulation

7.6 SFN Synchronization


8 DVB-H radio network

8.1 OFDM

8.2 DVB-H Radio frequency

8.3 Modulation

8.4 FFT mode

8.5 Guard interval

8.6 Error correction


9 Radio network dimensioning

9.1 Radio network planning process

9.2 Capacity

9.3 Link budget

9.4 Coverage area calculations

9.5 Trade-offs between the parameters

9.6 Radio network measurements and analysis

9.7 EMC and bio-effect calculations


10 Optimization of the network

10.1 Technical parameters

10.2 SFN size

10.3 Effect of transmitter power on network costs


11 Future

11 References

11.1 Litterature

11.2 Internet links


12 APPENDIX 1 : DVB standards list

12.1 Transmission

12.2 Multiplexing

12.3 Source coding

12.4 Subtitling

12.5 Interactivity

12.6 Middleware

12.7 Content protection and copy management

12.8 Interfacing

12.9 Internet protocol

12.10 Conditional access

12.11 Measurements

About the author

Jyrki T.J. Penttinen, Senior Solutions Architect, Nokia Siemens Networks, Spain currently plans technological solutions for the mobile network evolution, including the 2G and 3G radio networks. Previously he has worked in Technical Management for Nokia Mexico and USA. He also has extensive experience from the mobile networks operator side having worked in R&D Management in Spain and in other technical tasks in Finland. Among his other projects, he has participated in DVB-H standardization and trialling, and he is currently working on his PhD thesis which is related to the DVB-H planning and optimization. Jyrki has written telecommunications related books and he has given actively international telecoms presentations. Petri Jolma, Senior Specialist, Nokia Siemens Networks, Finland received the degree of M.S. of electrical engineering from the Technical University of Helsinki 1986, and has been employed by Nokia Networks / Nokia Siemens Networks since then. He has worked at several positions in microwave design, cellular network RF design and research, including DVB-H technology.
Erkki Aaltonen, Business Development Manager, Nokia Corporation, Finland has extensive business development and sales experience in telecommunication business, establishing strategic partnerships with key mobile players globally. He is recognized as a leader in mobile TV-related business modeling and specialises in DVB-H. Erkki is also a partner and Board Director at Piccola Onda.
Jani Väre, Project Manager, Nokia Corporation, Finland has a MSc. Degree in Information technology and he is currently finalizing his PhD thesis. He has worked in Nokia since 2001, participating closely in the activities related to MobileTV and DVB-H. Throughout his Nokia career he has contributed to the generation of new technologies within the field of Telecommunications and especially related to the MobileTV. The development of IPDC over DVB-H and DVB-T2 standards have been his latest major projects. Currently he is working closely in the development of the Next Generation Handheld (NGH) standard, which is the latest evolution of MobileTV within the DVB. He holds over 40 patents and patent applications. He is also named in the Marquis Who's Who in Science and Engineering and in the Marquis Who's Who in the World.

Summary

DVB-H is the leading global physical layer specification for the transmission of broadcast services to battery-powered handheld receivers, such as mobile phones and PDAs. The DVB-H Handbook describes the principles and details of the DVB-H system, giving a complete picture of its background, functioning, planning and optimization.

Product details

• Authors: Erkki Aaltonen, Erkki (Nokia Corporation) Aaltonen, Petr Jolma, Petri Jolma, Petri (Nokia Siemens Networks) Jolma, Petri (Nokia Siemens Networks) Aaltonen Jolma, J Penttinen, Jyrki Penttinen, Jyrki Jolma Penttinen, Jyrki T Penttinen, Jyrki T J Penttinen, Jyrki T. J. Penttinen, Jyrki T. J. (Nokia Siemens Networks) Penttinen, Jyrki T. J. (Nokia Siemens Networks) Jo Penttinen, Jyrki T. J. Jolma Penttinen, Jyrki/ Jolma Penttinen, PENTTINEN JYRKI JOLMA PETRI AALT, Jani Vare, Jani (Nokia Corporation) Vare, Jani Väre
• Publisher: Wiley, John and Sons Ltd
• Languages: English
• Product format: Hardback
• Released: 11.12.2009
• EAN: 9780470748299
• ISBN: 978-0-470-74829-9
• No. of pages: 270
• Subject: Natural sciences, medicine, IT, technology > Technology > Electronics, electrical engineering, communications engineering
