Quantum Semiconductor Devices and Technologies

English · Hardback

Shipping usually within 2 to 3 weeks (title will be printed to order)

Description

Read more

stacked QD structure and is useful for examining the possibility of all optical measurement of stacked QD layers. Optical absorption spectra of self-assembled QDs has been little reported, and further investigation in necessary to study hole-burning memory. 2.5 Summary This chapter describes recent advances in quantum dot fabrication tech nologies, focusing on our self-formed quantum dot technologies including TSR quantum dots and SK-mode self-assembled quantum dots. As is described in this chapter, there are many possible device applications such as quantum dot tunneling memory devices, quantum dot fioating-dot gate FETs, quantum dot lasers, and quantum dot hole-burning memory devices. The quantum dot laser applications seem to be the most practicable among these applications. However, many problems remain to be solved before even this application becomes practical. The most important issue is to of self-assembled quantum dots more pre control the size and position cisely, with an accuracy on an atomic scale. The confinement must be enough to keep the separation energy between quantized energy levels high enough to get high-temperature characteristics. The lasing oscillation frequency should be fixed at 1.3 f.lITl or 1.5 f.lITl for optical communication. Phonon bottleneck problems should be solved by the optimization of device structures. Fortunately, there is much activity in the area of quantum dot lasers and, therefore, many breakthroughs will be made, along with the exploration of other new application areas.

List of contents

1 Quantum nanocircuits: Chips of the future?.- 2 Self-formed quantum dot structures and their potential device application.- 3 Lithography and patterning for nanostructure fabrication.- 4 The use of MO-VPE to produce quantum structured semiconductors.- 5 Growth, characterization, and application of self-assembled InGaAs quantum dots.- 6 Structural characterization of self-organized Ge islands.

Summary

As is described in this chapter, there are many possible device applications such as quantum dot tunneling memory devices, quantum dot fioating-dot gate FETs, quantum dot lasers, and quantum dot hole-burning memory devices.

Product details

Assisted by To Pearsall (Editor), Tom Pearsall (Editor)
Publisher Springer, Berlin

Languages English
Product format Hardback
Released 29.06.2009

EAN 9780792377481
ISBN 978-0-7923-7748-1
No. of pages 266
Dimensions 163 mm x 241 mm x 21 mm
Weight 576 g
Illustrations VII, 266 p. 77 illus.
Series Electronic Materials Series
Electronic Materials Series
Subject Natural sciences, medicine, IT, technology > Technology > Electronics, electrical engineering, communications engineering
