Designed for senior electrical engineering students, this textbook explores the theoretical concepts of digital signal processing and communication systems by presenting laboratory experiments using real-time DSP hardware. Each experiment begins with a presentation of the required theory and concludes with instructions for performing them. Engineering students gain experience in working with equipment commonly used in industry. This text features DSP-based algorithms for transmitter and receiver functions.
List of contents
1. Brief Overview of the Hardware and Software Tools.- 2. Learning to Use the Hardware and Software Tools by Generating a Sine Wave.- 3. Digital Filters.- 4. The FFT and Power Spectrum Estimation.- 5. Amplitude Modulation.- 6. Double-Sideband Suppressed-Carrier Amplitude Modulation and Coherent Detection.- 7. Single-Sideband Modulation and Frequency Translation.- 8. Frequency Modulation.- 9. Pseudo-Random Binary Sequences and Data Scramblers.- 10. Introduction to the RS-232C Protocol and a Bit-Error Rate Tester.- 11. Digital Data Transmission by Baseband Pulse Amplitude Modulation (PAM).- 12. Fundamentals of Quadrature Amplitude Modulation.- 13. QAM Receiver I. General Description of Complete Receiver Block Diagram and Details of the Symbol Clock Recovery and Other Front-End Subsytems.- 14. QAM Receiver II. The Passband Adaptive Equalizer and Carrier Recovery System.- 15. Echo Cancellation for Full-Duplex Modems.- 16. Suggestions for Additional Experiments.- Appendix A. Communicating between the PC and EVM.- A.1. Overview of the PC/EVM Interface.- A.1.1. The Data Transfer Register.- A.1.2. EVM Interrupts to the TMS320C30.- A.1.3. Flags that Indicate to the PC when the TMS320C30 has Read or Written the Transfer Register.- A.1.4. Resetting the EVM.- A.2. A Command Passing Protocol.- A.3. Using DMA for Data Transfers.- A.3.1. TMS320C30 to PC Data Transfers.- A.3.2. PC to TMS320C30 Data Transfers.- A.3.3. Turning off the DMA.- A.4. Laboratory Experiments on Transferring Data between the TMS320C30 and PC.- A.4.1. Functions the TMS320C30 Program Must Perform.- A.4.2. Functions the PC Program Must Perform.- A.4.3. Testing Your PC and TMS320C30 Software.- Appendix B. Generating Gaussian Random Numbers.- Appendix C. A TTL/RS-232C Interface for Serial Port 1.- Appendix D. Equipment List for Each Station.- Appendix E. Software and Directory Structure.- References.- I. List of Manuals.- A. Manuals for the TMS320C30 Tools.- B. Manuals for Borland C++.- C. Assorted Manuals for Lab Test Equipment.- II. Selected Reference Books and Papers.- A. DSP Laboratory Books Using DSP Hardware.- B. DSP Laboratory Books Using Software Simulation.- C. Books on Digital Signal Processing.- D. Books and Papers on Communications.- E. Books and Papers on Error-Correcting Codes.
