This CIGRE Green book on accessories for HV and EHV extruded cables covers relevant issues in cable system design, cable design, submarine cables including off shore generation connection. It provides comprehensive and unbiased information, essential recommendations and guidelines for design, installation, testing and maintenance of accessories to professionals through the exceptional expertise of the authors.
This publication is divided in two Volumes covering land and submarine applications, HVAC and HVDC systems, transitions from lapped cable systems to extruded cable systems, from OHL to UG cables and from cables to substations. It equips the reader with recommendations for testing, installation, maintenance, remaining life management. This Volume is dedicated to Components while Volume 2 deals with Land and Submarine AC/DC Applications.
The book compiles the results of the work achieved by several Working Groups and Task Forces of CIGRE Study Committee 21/B1, and Joint Working Groups and Joint Task Forces with other Study Committees. Many experts from Study Committees 21/B1 (Insulated Cables), 15/D1 (Materials and Emerging Test Techniques), 33/B3 (Substations), C3 (System Environmental Performance) and C4 (System Technical Performance) have participated in this work in the last 30 years in order to offer comprehensive, continuous and consistent outputs.
List of contents
Compendium of Accessory Types Used for AC HV Extruded Cables.- A Guide to the Selection of Accessories.- Interfaces in Accessories for Extruded HV and EHV Cables.- Qualification Procedures for HV and EHVAC Extruded Underground Cable Systems.- Cable Accessory Workmanship on Extruded High Voltage Cables.- Guidelines for Maintaining the Integrity of Extruded Cable Accessories.- Feasibility of a Common, Dry Type Plug-in Interface for GIS and Power Cables above 52 kV.- Test Procedures for HV Transition Joints for Rated Voltages 30 kV up to 500 kV.- Thermal Ratings of HV Cable Accessories.- Test Regimes for HV and EHV Cable Connectors.- Standard Design of a Common, Dry Type Plug-in Interface for GIS and Power Cables up to 145 kV.
About the author
The
Study Committee B1 of CIGRE (Insulated Cables) covers underground and submarine, AC and DC, Insulated Cable Systems. SC B1 (formerly SC 21) was established in 1927 and celebrated its 80th anniversary during the 2007 Study Committee meeting in Osaka (Japan).
Pierre Argaut was graduated as electrical engineer
from the "Institut d'Electrotechnique de Grenoble" in
1971. He joined Delle-Alsthom (HV Switchgear Manufacturer)
in November 1971 and took several positions
before heading the R&D Department on GIS. After
being operation manager of South European Pipeline,
he joined SILEC in 1988 and retired at the end of 2010.
His last position with SILEC was senior vice president.
In Study Committee B1 (Insulated Cables), Pierre
has held position of working group member
(21.09;21.06;21.07;21.17), French SC member, working
group convener (B1.19), special reporter (2010),
advisory group convener (Tutorial Advisory Group till
2010), and chairman of SC B1 from August 2010 to
August 2016. He received the Technical Committee
Award in 2000, the Distinguished Member Award in
2002, and the title of Honorary Member of CIGRE in
2016.
