Investigations on AC losses of power cables with large cross-sections - This work studies a new measurement method for optimized conductors and verifies the results with numerical simulations

In this work, low-frequency simulations with the Computer Simulation Technology (CST) software have been investigated. After verifying simple models with analytical solutions, a model of a drummed power cable was simulated. As in recent measurements of cable manufacturers, it was shown that a drumming of a power cable with a solid aluminum screen leads to effects, which increase the AC resistance of the inner conductor. Additionally, measurements, simulations and analytical considerations concerning tubular conductors were performed. A formula for a tubular conductor close to its return conductor was developed. Furthermore simulations were able to replicate measured changes in the R_AC/R_DC-ratio at higher frequencies with solid conductors, which were previously falsely attributed to Milliken conductors.

About the author

Personal:1990: born in Berlin, GER//Education:2013: B.Eng.- TFH Berlin,2014:M.Sc.- TU Berlin//Experience:2009-'13:Siemens Real Estate,2013-'14:Siemens AG Energy Sector,Currently: research fellow TU Berlin//rel. Publication:A numerical approach to optimize HVAC conductor designs based on parameter sweeps of influenceable construction steps

Product details

• Authors: René Suchantke
• Publisher: AV Akademikerverlag
• Languages: English
• Product format: Paperback / Softback
• Released: 31.07.2015
• EAN: 9783639851878
• ISBN: 978-3-639-85187-8
• No. of pages: 96
• Subject: Natural sciences, medicine, IT, technology > Technology > Electronics, electrical engineering, communications engineering
