A fully comprehensive examination of state-of-the-art technologies for measurement at the small scale
* Highlights the advanced research work from industry and academia in micro-nano devices test technology
* Written at both introductory and advanced levels, provides the fundamentals and theories
* Focuses on the measurement techniques for characterizing MEMS/NEMS devices
List of contents
About the Authors ix
Preface xi
1 Introduction 1
1.1 Micro/Nanotechnology 1
1.1.1 Development of MEMS 1
1.1.2 Development of NEMS 3
1.2 Development of Micro/Nanoscale Measurements 5
1.2.1 Significance 5
1.2.2 Types of Micro/Nanoscale Measurements 6
1.2.3 Conclusion and Outlook 7
References 9
2 Geometry Measurements at the Micro/Nanoscale 11
2.1 Microvision Measurement 11
2.1.1 Micro/Nanoscale Plane Geometry Parameter Tests 11
2.1.2 Integrality Tests and Analysis of Micro/Nanometer Structures 12
2.1.3 Micro/Nanoscale Plane Dynamic Characteristic Tests 13
2.2 3D Morphology Measurements in Contact Mode 15
2.2.1 Scanning Probe Microscopy 15
2.2.2 Near-Field Scan Optics Microscopy (NSOM) 21
2.2.3 Scanning Electron Microscopy 26
2.2.4 Transmission Electron Microscopy 31
2.3 3D Morphology Optics Measurements with Non-Contact Modes 36
2.3.1 Laser Scanning Microscopy 37
2.3.2 White Light Interferometry Morphology Measurements 40
2.4 Micro/Nanoscale Tricoordinate Measurements 63
2.4.1 Basics 64
2.4.2 Experimental Techniques 67
2.5 Measurement of Film Thickness 71
References 77
3 Dynamic Measurements at the Micro/Nanoscale 79
3.1 Stroboscopic Dynamic Vision Imaging 79
3.1.1 Principles of Plane Dynamic Measurements 80
3.1.2 Equipment 81
3.1.3 Block Matching and Phase Correlation Methods 84
3.1.4 Optical Flow Field Measurement Method 86
3.2 Stroboscopic Microscopy Interference Measurements 90
3.2.1 Principles 90
3.2.2 Equipment 92
3.2.3 System 93
3.3 Laser Doppler Microscope Vibration Measurements 94
3.3.1 Differential Doppler Vibration Measurements 98
3.3.2 Laser Torsional Vibration Measurements 99
3.3.3 Laser Doppler Vibration Measurements of Single Torsional Vibrations and Single Bend Vibrations 100
3.3.4 Laser Doppler Flutter Measurements 103
3.4 Conclusion 104
3.4.1 Mechanical Processes in AFM 104
3.4.2 Measurement Theory and Methods of Micro/Nanometer Mechanics in AFM 106
3.4.3 Micro/Nano Measurement System and Reference Cantilever Measurement Method in AFM 112
3.4.4 Measurement of Spring Constant of Cantilever and System Verification 115
3.4.5 Application of AFM to Nanometrology 117
References 119
4 Mechanical Characteristics Measurements 121
4.1 Residual Stress Measurements of Microstructures 122
4.1.1 Residual Stress 122
4.1.2 Measurements 122
4.2 Axial Tensile Measurement 131
4.2.1 Traditional Tensile Method 131
4.2.2 Conversion Tensile Method 136
4.2.3 Integrated Tensile Method 137
4.2.4 Displacement Measurement of Uniaxial Tension 138
4.3 Nano-Indentation Measurements Using Contact Dode 140
4.3.1 Basic Principles of Nano-Indentation Technology 140
4.3.2 Nano-Indentation Measurements 148
4.3.3 Features of Nano-Indentation Technology 150
4.4 Bend Method 151
4.4.1 Principles 151
4.4.2 Micro/Nanobeams 154
4.4.3 Advantages and Disadvantages of the Bend Method 157
4.5 Resonance Method 157
4.5.1 Resonance Frequency 158
4.5.2 Intrinsic Resonance Frequency 159
4.6 Stress Measurements Based on Raman Spectroscopy 160
4.6.1 Raman Scattering 160
4.6.2 Theory 161
4.6.3 Experimental Techniques 162
About the author
WENDONG ZHANG, North University of China, China XIUJIAN CHOU, North University of China, China TIELIN SHI, Huazhong University of Science and Technology, China ZONGMIN MA, North University of China, China HAIFEI BAO, Shanghai Institute of Microsystem and Information Technology, Chinese Academy of Sciences, China JING CHEN, Peking University, China LIGUO CHEN, Soochow University, China DACHAO LI, Tianjin University, China CHENYANG XUE, Key Laboratory of Instrument Science and Dynamic Measurement, Ministry of Education, China
Summary
Dealing with the technologies for measurement at the small scale, this book highlights the advanced research work from industry and academia in micro-nano devices test technology Written at both introductory and advanced levels, provides the fundamentals and theories.
