Orifice Plates and Venturi Tubes

This book gives the background to differential-pressure flow measurement and goes through the requirements explaining the reason for them. For those who want to use an orifice plate or a Venturi tube the standard ISO 5167 and its associated Technical Reports give the instructions required. However, they rarely tell the users why they should follow certain instructions. This book helps users of the ISO standards for orifice plates and Venturi tubes to understand the reasons why the standards are as they are, to apply them effectively, and to understand the consequences of deviations from the standards.

List of contents

Introduction.- Orifice Design.- Venturi Design.- General Design.- Orifice Discharge Coefficient.- Orifice Expansibility Factor.- Venturi tube discharge coefficient in high-pressure gas.- Installation effects.- Nozzles.- Orifice plates with drain holes.- Wet gas.- Standards.

About the author

Dr Reader-Harris is Principal Consultant in flow measurement at NEL.  He provides technical leadership to projects, carries out consultancy work particularly in the area of differential pressure meters, and undertakes work in support of Standards.

Summary

This book gives the background to differential-pressure flow measurement and goes through the requirements explaining the reason for them. For those who want to use an orifice plate or a Venturi tube the standard ISO 5167 and its associated Technical Reports give the instructions required.  However, they rarely tell the users why they should follow certain instructions.  This book helps users of the ISO standards for orifice plates and Venturi tubes to understand the reasons why the standards are as they are, to apply them effectively, and to understand the consequences of deviations from the standards.

Product details

• Authors: Michael Reader-Harris
• Publisher: Springer, Berlin
• Languages: English
• Product format: Hardback
• Released: 14.06.2015
• EAN: 9783319168791
• ISBN: 978-3-31-916879-1
• No. of pages: 393
• Dimensions: 161 mm x 29 mm x 242 mm
• Weight: 751 g
• Illustrations: XVIII, 393 p. 220 illus., 192 illus. in color.
• Series: Experimental Fluid Mechanics; Experimental Fluid Mechanics
• Subjects: Natural sciences, medicine, IT, technology > Technology > Mechanical engineering, production engineering; Maschinenbau, B, Wissenschaftliche Standards, Normung usw., engineering, Measurement, Mechanical Engineering, Fluid mechanics, Engineering Fluid Dynamics, Scientific standards, measurement etc, Measurement Science and Instrumentation, Physical measurements
