Informationen zum Autor Anatol I. Zverev is the author of Handbook of Filter Synthesis, published by Wiley. Klappentext Handbook of Filter Synthesis, originally published in 1967 is the classic reference for continuous time filter design. The plots of filter behaviour for different designs, such as ripple and group delay, make this book invaluable. The discussion of how to synthesize a bandpass, bandpass, or bandstop filter from a lowpass prototype is also very useful. Zusammenfassung Handbook of Filter Synthesis, originally published in 1967 is the classic reference for continuous time filter design. The plots of filter behaviour for different designs, such as ripple and group delay, make this book invaluable. Inhaltsverzeichnis Chapter 1 Filters in Electronics 1 1.1 Types of Filters 1 1.2 Filter Applications 3 1.3 All-Pass Filters 5 1.4 Properties of Lattice Filters 6 1.5 Filter Building Blocks 9 1.6 Higher Order Filters 17 1.7 Coil-Saving Bandpass Filters 17 1.8 Frequency Range of Applications 20 1.9 Physical Elements of the Filter 21 1.10 Active Bandpass Filters 22 1.11 RC Passive and Active Filters 22 1.12 Microwave Filters 25 1.13 Parametric Filters 29 Chapter 2 Theory of Effective Parameters 31 2.1 Power Balance 32 2.2 Types of General Network Equations 33 2.3 Effective Attenuation 35 2.4 Reflective (Echo) Attenuation 36 2.5 Transmission Function as a Function of Frequency Parameter, s 37 2.6 Polynomials of Transmission and Filtering Functions 38 2.7 Filter Networks 39 2.8 Voltage and Current Sources 41 2.9 The Function D(s) As an Approximation Function 42 2.10 Examples of Transmission Function Approximation 45 2.11 Simplest Polynomial Filters in Algebraic Form 49 2.12 Introduction to Image-Parameter Theory 50 2.13 Bridge Networks 52 2.14 Examples of Realization in the Bridge Form 53 2.15 Hurwitz Polynomial 54 2.16 The Smallest Realizable Networks 55 2.17 Fourth-Order Networks 57 2.18 Fifth-Order Networks 58 Chapter 3 Filter Characteristics in The Frequency Domain 60 3.1 Amplitude Responses 60 3.2 Phase-and Group-Delay Responses 61 3.3 Group Delay of an Idealized Filter 61 3.4 Group-Delay-Attenuation Relationship 61 3.5 The Chebyshev Family of Response Characteristics 62 3.6 Gaussian Family of Response Characteristics 67 3.7 A Filter with Transitional Magnitude Characteristics 74 3.8 Legendre Filters 74 3.9 Minimum-Loss Characteristics 76 3.10 Synchronously Tuned Filters 76 3.11 Arithmetically Symmetrical Bandpass Filters 77 3.12 Attenuation Characteristics of Image Parameter Filters 78 3.13 Other Types of Filter Characteristics 80 3.14 Plots of the Attenuation and Group Delay Characteristics 81 Chapter 4 Elliptic Functions and Elements of Realization 107 4.1 Double Periodic Elliptic Functions 107 4.2 Mapping of s-Plane into u-Plane 109 4.3 First Basic Transformation of Elliptic Functions 110 4.4 Filtering Function in z-Plane 112 4.5 Graphical Representation of Parameters 114 4.6 Characteristic Values of D(s) 115 4.7 An Example of Filter Design 116 4.8 Consideration of Losses 119 4.9 Introduction of Losses by Frequency Transformation 119 4.10 Highpass Filters with Losses 120 4.11 Transmission Functions with Losses 121 4.12 Conclusions on Consideration of Losses 123 4.13 Realization Process 124 4.14 Bandpass Filter with a Minimum Number of Inductors 125 4.15 The Elements of a Coil-Saving Network 127 4.16 Consideration of Losses in Zig-Zag Filters 128 4.17 Realization Procedure 129 4.18 Numeric...
