Informationen zum Autor Dr. Cecil Smith has over 35 years experience in process control, and his expertise encompasses virtually every control technology being applied in industrial production facilities. His primary focus is on designing a control strategy for a process and then commissioning the controls, that is, the process aspects as opposed to systems aspects. However, he is proficient with both DCS's, PLC's, PC-based controls, and single-loop microprocessor-based controls, and is capable of resolving both process and system problems. Dr. Smith has equally extensive experience in teaching continuing education courses for practicing engineers on various aspects of process control and instrumentation. Klappentext Gives a real world explanation of how to analyze and troubleshoot a process control system in a batch process plant* Explains how to analyze the requirements for controlling a batch process, develop the control logic to meet these requirements, and troubleshoot the process controls in batch processes* Presents three categories of batch processes (cyclical batch, multigrade facilities, and flexible batch) and examines the differences in the control requirements in each* Examines various concepts of a product recipe and what its nature must be in a flexible batch facility* Approaches the subject from the process perspective, with emphasis on the advantages of using structured logic in the automation of all but the simplest batch processes.* Discusses the flow of information starting at the plant floor and continuing through various levels of the control logic up to the corporate IT level Zusammenfassung Batch processing is used extensively in the pharmaceutical, biotechnology, coatings, and electronic materials industries, where new jobs are being created. Inhaltsverzeichnis Preface ix 1 Introduction 1 1.1. Categories of Processes 3 1.2. The Industry 5 1.3. The Ultimate Batch Process: The Kitchen in Your Home 13 1.4. Categories of Batch Processes 14 1.5. Automation Functions Required for Batch 18 1.6. Automation Equipment 26 Reference 30 2 Measurement Considerations 31 2.1. Temperature Measurement 32 2.2. Pressure Measurement 39 2.3. Weight and Level 47 2.4. Flow Measurements 61 2.5. Loss-in-Weight Application 67 References 72 3 Continuous Control Issues 73 3.1. Loops That Operate Intermittently 74 3.2. Emptying a Vessel 80 3.3. Terminating a Co-Feed 85 3.4. Adjusting Ratio Targets 89 3.5. Attaining Temperature Target for the Heel 97 3.6. Characterization Functions in Batch Applications 100 3.7. Scheduled Tuning in Batch Applications 101 3.8. Edge of the Envelope 104 3.9. No Flow Through Control Valve 107 3.10. No Pressure Drop across Control Valve 111 3.11. Attempting to Operate above a Process-Imposed Maximum 115 3.12. Attempting to Operate Below a Process-Imposed Minimum 121 3.13. Jacket Switching 124 3.14. Smooth Transitions between Heating and One Cooling Mode 129 3.15. Smooth Transitions between Two Cooling Modes 140 References 148 4 Discrete Devices 149 4.1. Discrete Inputs 149 4.2. Discrete Outputs 157 4.3. State Feedbacks 167 4.4. Associated Functions 176 4.5. Beyond Two-State Final Control Elements 182 5 Material Transfers 185 5.1. Multiple-Source, Single-Destination Material Transfer System 186 5.2. Single-Source, Multiple-Destination Material Transfer System 189 5.3. Multiple-Source, Multiple-Destination Material Transfer System 191 5.4. Validating a Material Transfer 194 5.5. Dribble Flow 197 5.6. Simultaneous Material Transfers 202 5.7. Drums 203 6 Structured Logic for Batch 205
