Introduction to Lte - Lte, Lte-Advanced, Sae, Volte and 4g Mobile Communications

Following on from the successful first edition (March 2012), this book gives a clear explanation of what LTE does and how it works. The content is expressed at a systems level, offering readers the opportunity to grasp the key factors that make LTE the hot topic amongst vendors and operators across the globe. The book assumes no more than a basic knowledge of mobile telecommunication systems, and the reader is not expected to have any previous knowledge of the complex mathematical operations that underpin LTE.

This second edition introduces new material for the current state of the industry, such as the new features of LTE in Releases 11 and 12, notably coordinated multipoint transmission and proximity services; the main short- and long-term solutions for LTE voice calls, namely circuit switched fallback and the IP multimedia subsystem; and the evolution and current state of the LTE market. It also extends some of the material from the first edition, such as inter-operation with other technologies such as GSM, UMTS, wireless local area networks and cdma2000; additional features of LTE Advanced, notably heterogeneous networks and traffic offloading; data transport in the evolved packet core; coverage and capacity estimation for LTE; and a more rigorous treatment of modulation, demodulation and OFDMA. The author breaks down the system into logical blocks, by initially introducing the architecture of LTE, explaining the
techniques used for radio transmission and reception and the overall operation of the system, and concluding with more specialized topics such as LTE voice calls and the later releases of the specifications. This methodical approach enables readers to move on to tackle the specifications and the more advanced texts with confidence.

List of contents

Preface xxi

Acknowledgements xxiii

List of Abbreviations xxv

1 Introduction 1

1.1 Architectural Review of UMTS and GSM 1

1.2 History of Mobile Telecommunication Systems 6

1.3 The Need for LTE 8

1.4 From UMTS to LTE 11

1.5 From LTE to LTE-Advanced 16

1.6 The 3GPP Specifications for LTE 17

References 19

2 System Architecture Evolution 21

2.1 High-Level Architecture of LTE 21

2.2 User Equipment 21

2.3 Evolved UMTS Terrestrial Radio Access Network 23

2.4 Evolved Packet Core 25

2.5 Communication Protocols 30

2.6 Example Signalling Flows 34

2.7 Bearer Management 36

2.8 State Diagrams 40

2.9 Spectrum Allocation 43

References 45

3 Digital Wireless Communications 49

3.1 Radio Transmission and Reception 49

3.2 Radio Transmission in a Mobile Cellular Network 56

3.3 Impairments to the Received Signal 58

3.4 Error Management 61

References 65

4 Orthogonal Frequency Division Multiple Access 67

4.1 Principles of OFDMA 67

4.2 Benefits and Additional Features of OFDMA 75

4.3 Single Carrier Frequency Division Multiple Access 82

References 85

5 Multiple Antenna Techniques 87

5.1 Diversity Processing 87

5.2 Spatial Multiplexing 90

5.3 Beamforming 101

References 104

6 Architecture of the LTE Air Interface 105

6.1 Air Interface Protocol Stack 105

6.2 Logical, Transport and Physical Channels 107

6.3 The Resource Grid 111

6.4 Multiple Antenna Transmission 118

6.5 Resource Element Mapping 119

References 123

7 Cell Acquisition 125

7.1 Acquisition Procedure 125

7.2 Synchronization Signals 126

7.3 Downlink Reference Signals 128

7.4 Physical Broadcast Channel 129

7.5 Physical Control Format Indicator Channel 130

7.6 System Information 131

7.7 Procedures after Acquisition 133

References 134

8 Data Transmission and Reception 135

8.1 Data Transmission Procedures 135

8.2 Transmission of Scheduling Messages on the PDCCH 139

8.3 Data Transmission on the PDSCH and PUSCH 144

8.4 Transmission of Hybrid ARQ Indicators on the PHICH 148

8.5 Uplink Control Information 149

8.6 Transmission of Uplink Control Information on the PUCCH 153

8.7 Uplink Reference Signals 155

8.8 Power Control 157

8.9 Discontinuous Reception 159

References 161

9 Random Access 163

9.1 Transmission of Random Access Preambles on the PRACH 163

9.2 Non-Contention-Based Procedure 166

9.3 Contention-Based Procedure 167

References 169

10 Air Interface Layer 2 171

10.1 Medium Access Control Protocol 171

10.2 Radio Link Control Protocol 176

10.3 Packet Data Convergence Protocol 180

References 183

11 Power-On and Power-Off Procedures 185

11.1 Power-On Sequence 185

11.2 Network and Cell Selection 187

11.3 RRC Connection Establishment 189

11.4 Attach Procedure 191

11.5 Detach Procedure 199

References 200

12 Security Procedures 203

12.1 Network Access Security 203

12.2 Network Domain Security 210

References 212

13 Quality of Service, Policy and Charging 215

13.1 Policy and Charging Control 215
&n

About the author

Christopher Cox is a professional technical trainer and consultant in mobile telecommunications. He is an expert in the technical and radio network planning aspects of LTE and UMTS, and regularly delivers training courses about them to audiences drawn from equipment manufacturers, network operators and consultancies worldwide. He has a degree in Physics and a PhD in Radio Astronomy from the University of Cambridge and 20 years' experience in scientific and technical consultancy, telecommunications and training.

Summary

Following on from the successful first edition (March 2012), this book gives a clear explanation of what LTE does and how it works. It assumes no more than a basic knowledge of mobile telecommunication systems, and the reader is not expected to have any previous knowledge of the complex mathematical operations that underpin LTE.

Product details

• Authors: Baggy Cox, C Cox, Christopher Cox
• Publisher: Wiley, John and Sons Ltd
• Languages: English
• Product format: Hardback
• Released: 11.07.2014
• EAN: 9781118818039
• ISBN: 978-1-118-81803-9
• No. of pages: 488
• Subject: Natural sciences, medicine, IT, technology > Technology > Electronics, electrical engineering, communications engineering
