Cutting-edge techniques for designing analog filters and circuits
With an emphasis on using operational amplifiers as key building blocks, Analog Filter and Circuit Design Handbook shows how to create working circuits that perform a variety of analog functions. Numerous circuit examples provide mathematical functions on analog signals in both a linear and nonlinear manner. The highly efficient elliptic-function filter response is featured throughout the book. Audio applications, such as audio power amplifiers and cross-over networks, are discussed, and both voltage and current feedback amplifiers are covered. This practical guide also analyzes the impact of nonideal amplifiers and addresses waveform shaping and generation.
ANALOG FILTER AND CIRCUIT DESIGN HANDBOOK COVERS:
Introduction to modern network theory
Selecting the response characteristic
Low-pass filter design
High-pass filter design
Bandpass filters
Band reject filters
Networks for the time domain
Refinements in LC filter design and the use of resistive networks
Component selection for LC and active filters
Normalized filter design tables
Switched capacitor filters
Adjustable, fixed delay, and amplitude equalizers
Voltage feedback operational amplifiers
Linear amplifier applications
Nonlinear circuits
Waveform shaping
Waveform generation
Current feedback amplifiers
Large signal amplifiers
INCLUDES FREE DOWNLOADS:
Filter Solutions from Nuhertz Technologies
ELI 1.0 Elliptic function filter design program
Fltrform--an Excel spreadsheet with essential formulas
List of contents
Preface
Ch. 1.Introduction to Modern Network Theory Using the Pole-Zero Concept
Ch. 2.Selecting the Filter Response Characteristic
Ch. 3.Low-Pass Filter Design
Ch. 4.High-Pass Filter Design
Ch. 5.Bandpass Filters
Ch. 6.Band-Reject Filters
Ch. 7.Networks for the Time Domain
Ch. 8.Refinements in LC Filter Design
Ch. 9.Capacitor and Resistor Selection for LC and Active Filters
Ch. 10.Normalized Filter Design Tables
Ch. 11.Switched Capacitor Filters
Ch. 12.Equalizers
Ch. 13.V.oltage Feedback Operational Amplifiers
Ch. 14.Current Feedback Operational Amplifiers
Ch. 15.Linear Amplifier Applications
Ch. 16.Non-Linear Amplifier Applications
Ch. 17.Waveform Generation and Shaping
Ch. 18.Large Signal Amplifiers
Appendix: Software Summary
Index
About the author
McGraw-Hill authors represent the leading experts in their fields and are dedicated to improving the lives, careers, and interests of readers worldwide
Summary
A single-source design reference providing expert guidance on analog filter and circuit design
