A novel and timely primer to the 3DTV system chain from capture to display
This book examines all aspects of the 3DTV chain, from capture to display. It helps the reader learn about the key issues for 3DTV technology. It also provides with a systems level appreciation of 3DTV systems, and an understanding of the fundamental principles behind each part of the chain. At the end of each chapter, the author provides resources where readers can learn more about the technology covered (e.g. more focused text books, key journal papers, and key standards contributions).
* Provides a fundamental and systematic introduction and description of 3DTV key techniques, which build up the whole 3DTV system from capture to consumer viewing at the home.
* Addresses the quick moving field of 3D displays which is attracting increasing interest from industry and academia.
* Concepts in the book will be illustrated using diagrams and example images of processed 3D content. The 3D content will be presented as 2D images in the book.
* Authors to host website providing pointers to more information on the web, freely available tools which would enable readers to experiment with coding video, simulate its transmission over networks, play it back in 3D, and measure the quality and links to important news and developments in the field.
List of contents
Preface ix
Acknowledgements xi
List of Abbreviations xiii
1 Introduction 1
1.1 History of 3D Video 2
1.1.1 3D in the Nineteenth Century 3
1.1.2 Early Twentieth-Century Developments 4
1.1.3 The 1950s 'Golden' Period 6
1.1.4 The 1980s Revival and the Arrival of IMAX 8
1.1.5 The Twenty-first-Century Revival 12
1.1.6 Auto-Stereoscopic 13
1.1.7 3D Television Broadcasts 14
1.2 3D Video Formats 17
1.2.1 Frame Compatible and Service Compatible Stereoscopic Video 17
1.2.2 Colour-Plus-Depth 20
1.2.3 Multi-View Video 22
1.2.4 Multi-View Plus Depth Video 23
1.2.5 Layered Depth Video 23
1.3 3D Video Application Scenarios 25
1.3.1 3DTV Broadcast Systems 25
1.3.2 Mobile 3DTV 26
1.3.3 3D Video on Demand 27
1.3.4 3D Immersive Video-Conferencing 28
1.3.5 Remote Applications 29
1.4 Motivation 29
1.5 Overview of the Book 30
References 31
2 Capture and Processing 34
2.1 3D Scene Representation Formats and Techniques 34
2.2 3D Video Capturing Techniques 36
2.2.1 Camera Technologies 37
2.2.2 Stereoscopic Video Capture 39
2.2.3 Multi-View Video Capture 45
2.2.4 Integral Imaging Capture 50
2.3 3D Video Processing 52
2.3.1 Rectification and Colour Correction 54
2.3.2 Extraction of Range Images 56
References 59
3 Compression 61
3.1 Video Coding Principles 61
3.2 Overview of Traditional Video Coding Standards 64
3.2.1 Overview of MPEG-4 Part 10/H.264 AVC Standard 65
3.2.2 High Efficiency Video Coding (HEVC) 68
3.3 3D Video Coding 71
3.3.1 Stereoscopic Video Coding 71
3.3.2 Multi-View Video Coding 73
3.3.3 Coding of Multi-View Plus Depth 78
3.4 Recent Trends in 3D Video Coding 84
3.4.1 3D Video with AVC-Based Coding Technology 86
3.4.2 3D Video with HEVC-Based Coding Technology 86
References 87
4 Transmission 91
4.1 Challenges of 3D Video Transmission 91
4.2 Error Resilience and Concealment Techniques 91
4.2.1 Background 92
4.2.2 Error Resilience Tools 93
4.2.3 Forward Error Correction (FEC) 97
4.3 3D Video Transmission: Example Scenarios 98
4.3.1 3D Video Broadcast over DVB-T 98
4.3.2 3D Video Streaming over IP Networks 102
4.3.3 3D Video Transmission over Mobile Broadband 105
4.4 Conclusion 121
References 121
5 Rendering, Adaptation and 3D Displays 123
5.1 Why Rendering? 123
5.2 3D Video Rendering 124
5.3 3D Video Adaptation 135
5.3.1 Importance of the Depth Map in Adaptation 135
5.3.2 Context Adaptation 136
5.3.3 3D Video Adaptation for Mobile Terminals 136
5.3.4 Multi-View Video Adaptation 138
5.4 3D Display Technologies 140
5.4.1 Anaglyphic Stereoscopic Displays 141
5.4.2 Passive Stereoscopic Displays 142
5.4.3 Active Stereoscopic Displays 143
5.4.4 Auto-Stereoscopic Displays 144
5.4.5 Light-Field Display 146
References 148
6 Quality Assessment 150
6.1 2D Video Quality Metrics 150
6.1.1 Peak-Signal-to-Noise-Ratio (PSNR) 151
6.1.2 Structural Similarity Index (SSIM) 151
6.1.3 Video Quality Metric (VQM) 151
6.2 3D Video Quality 152
6.2.1 Image Quality 153
6.2.2 Visual P
About the author
Anil Fernando, CVSSP,
University of Surrey, UK Stewart T. Worrall,
Ericsson Television, UK Erhan Ekmekcioglu, CVSSP,
University of Surrey, UK
Summary
* Provides a fundamental and systematic introduction and description of 3DTV key techniques, which build up the whole 3DTV system from capture to consumer viewing at the home. * Addresses the quick moving field of 3D displays which is attracting increasing interest from industry and academia.
