Broadband Opto-Electrical Receivers in Standard CMOS starts from the basic fundamentals necessary for the design of opto-electronic interface circuits. The book continues with an in-depth analysis of the photodiode, transimpedance amplifier (TIA) and limiting amplifier (LA). To thoroughly understand the light detection mechanisms in silicon, first a one-dimensional and second a two-dimensional model is developed. Analytical design equations are derived to guide the design of the amplifying circuits. For the TIA, the focus is on the sensitivity-speed trade-off. For the LA, a high gain-bandwidth is pursued. Several practical design examples reveal the subtleties and challenges encountered during the design of high-performance analog circuits.
Broadband Opto-Electrical Receivers in Standard CMOS covers the total design flow of monolithic CMOS optical receivers. All material is experimentally verified with several CMOS implementations, with ultimately a fully integrated Gbit/s optical receiver front-end including photodiode, TIA and LA.
List of contents
Optical Receiver Fundamentals.- Standard CMOS Photodiodes.- Transimpedance Amplifier Design.- Post-Amplifier Design.- CMOS Realizations.- Conclusions.
About the author
Prof. Michiel Steyaert has (co-)authored numerous books for Springer, all are "typical" monographs which have sold well.
Summary
Broadband Opto-Electrical Receivers in Standard CMOS starts from the basic fundamentals necessary for the design of opto-electronic interface circuits. The book continues with an in-depth analysis of the photodiode, transimpedance amplifier (TIA) and limiting amplifier (LA). To thoroughly understand the light detection mechanisms in silicon, first a one-dimensional and second a two-dimensional model is developed. Analytical design equations are derived to guide the design of the amplifying circuits. For the TIA, the focus is on the sensitivity-speed trade-off. For the LA, a high gain-bandwidth is pursued. Several practical design examples reveal the subtleties and challenges encountered during the design of high-performance analog circuits.
Broadband Opto-Electrical Receivers in Standard CMOS covers the total design flow of monolithic CMOS optical receivers. All material is experimentally verified with several CMOS implementations, with ultimately a fully integrated Gbit/s optical receiver front-end including photodiode, TIA and LA.
