Rf Analog Impairments Modeling for Communication Systems Simulation - Application to Ofdm-Based Transceivers

Informationen zum Autor Lydi Smaïni, Marvell Technology Group Ltd., Switzerland Dr. Smaïni is currently RF System & DSP group manager at Marvell's operations in Switzerland, a leading semiconductor company. In 2010 Dr. Smaïni gave a tutorial on RF System Design for Advanced Wireless Transceivers at the IEEE Solid-State Circuits Conference. Previously he has worked as an R&D consulting engineer for ALTEN, Marseille, France, where he developed a frequency agile radar beacon for navigation aid, which is now in service on the French coastline. Immediately prior to joining Marvell in 2006, from 2002 he was with STMicroelectronics, Switzerland in the RF System and Architecture Group for wireless communications working on Ultra Wide-Band impulse radio, 3G cellular phones, and advanced radio architectures for OFDMA technology. Klappentext With the growing complexity of personal mobile communication systems demanding higher data-rates and high levels of integration using low-cost CMOS technology, overall system performance has become more sensitive to RF analog front-end impairments. Designing integrated transceivers requires a thorough understanding of the whole transceiver chain including RF analog front-end and digital baseband. Communication system engineers have to include RF analog imperfections in their simulation benches in order to study and quantify their impact on the system performance.Here the author explores key RF analog impairments in a transceiver and demonstrates how to model their impact from a communication system design view-point. He discusses the design aspects of the front end of transceivers (both receivers and transmitters) and provides the reader with a way to optimize a complex mixed-signal platform by taking into account the characteristics of the RF/analog front-end.Key features of this book include:* Practical examples illustrated by system simulation results based on WiFi and mobile WiMAX OFDM transceivers* An overview of the digital estimation and compensation of the RF analog impairments such as power amplifier distortion, quadrature imbalance, and carrier and sampling frequency offsets* An exposition of the challenges involved in the design of both RF analog circuits and DSP communication circuits in deep submicron CMOS technology* MATLAB(r) codes for RF analog impairments models hosted on the companion websiteUniquely the book bridges the gap between RFIC design specification needs and communication systems simulation, offering readers RF analog impairments modeling knowledge and a comprehensive approach to unifying theory and practice in system modelling. It is of great value to communication systems and DSP engineers and graduate students who design communication processing engines, RF/analog systems and IC design engineers involved in the design of communication platforms. Zusammenfassung With the growing complexity of personal mobile communication systems demanding higher data-rates and high levels of integration using low-cost CMOS technology, overall system performance has become more sensitive to RF analog front-end impairments. Designing integrated transceivers requires a thorough understanding of the whole transceiver chain including RF analog front-end and digital baseband. Communication system engineers have to include RF analog imperfections in their simulation benches in order to study and quantify their impact on the system performance.Here the author explores key RF analog impairments in a transceiver and demonstrates how to model their impact from a communication system design view-point. He discusses the design aspects of the front end of transceivers (both receivers and transmitters) and provides the reader with a way to optimize a complex mixed-signal platform by taking into account the characteristics of the RF/analog front-end.Key features of this book include:* Practical examples illustrated by system simulation res...

List of contents

Preface xi

Acknowledgments xiii

About the Author xv

1 Introduction to Communication System-on-Chip, RF Analog Front-End, OFDM Modulation, and Performance Metrics 1

1.1 Communication System-on-Chip 1

1.1.1 Introduction 1

1.1.2 CMOS Technology 3

1.1.3 Coexistence Issues 4

1.2 RF AFE Overview 6

1.2.1 Introduction 6

1.2.2 Superheterodyne Transceiver 8

1.2.3 Homodyne Transceiver 10

1.2.4 Low-IF Transceiver 11

1.2.5 Analog Baseband Filter Order versus ADC Dynamic Range 12

1.2.6 Digital Compensation of RF Analog Front-End Imperfections 13

1.3 OFDM Modulation 14

1.3.1 OFDM as a Multicarrier Modulation 14

1.3.2 Fourier Transform and Orthogonal Subcarriers 15

1.3.3 Channel Estimation and Equalization in Frequency Domain 18

1.3.4 Pilot-Tones 20

1.3.5 Guard Interval 21

1.3.6 Windowed OFDM 21

1.3.7 Adaptive Transmission 22

1.3.8 OFDMA for Multiple Access 23

1.3.9 Scalable OFDMA 23

1.3.10 OFDM DBB Architecture 24

1.3.11 OFDM-Based Standards 27

1.4 SNR, EVM, and

1.4.1 Bit Error Rate 27

1.4.2 SNR versus EVM 28

1.4.3 SNR versus E

1.4.4 Complex Baseband Representation 32

References 34 Eb/N0 Definitions and Relationship 27b/N0 31

2 RF Analog Impairments Description and Modeling 37

2.1 Introduction 37

2.2 Thermal Noise 38

2.2.1 Additive White Gaussian Noise 38

2.2.2 Noise Figure and Sensitivity 40

2.2.3 Cascaded Noise Voltage in IC Design 41

2.2.4 AWGN in Simulations 42

2.2.5 Flicker Noise and AWGN Modeling 43

2.3 Oscillator Phase Noise 44

2.3.1 Description and Impact on the System 44

2.3.2 Phase Noise Modeling in the Frequency Domain 45

2.3.3 Simulation in Temporal Domain 49

2.3.4 SNR Limitation due to the Phase Noise 50

2.3.5 Impact of Phase Noise in OFDM 52

2.4 Sampling Jitter 57

2.4.1 Jitter Definitions 57

2.4.2 Sampling Jitter and Phase Noise Relationship 58

2.4.3 SNR Limitation due to Sampling Jitter 61

2.4.4 Impact of Sampling Jitter in OFDM 63

2.4.5 Sampling Jitter Modeling 63

2.5 Carrier Frequency Offset 64

2.5.1 Description 64

2.5.2 Impact of CFO in OFDM 65

2.6 Sampling Frequency Offset 67

2.6.1 Description 67

2.6.2 Impact of SFO in OFDM 68

2.7 I and Q Mismatch 71

2.7.1 Description 71

2.7.2 IQ Mismatch Modeling 76

2.7.3 SNR Limitation due to IQ Mismatch 76

2.7.4 Impact of IQ Mismatch in OFDM 78

2.8 DAC/ADC Quantization Noise and Clipping 79

2.8.1 SNR Limitation due to the Quantization Noise and Clipping Level 79

2.8.2 Impact of Converter Clipping Level in OFDM 82

2.8.3 DAC and ADC Dynamic Range in OFDM 84

2.8.4 DAC and ADC Modeling 86

2.9 IP2 and IP3: Second- and Third-Order Nonlinearities 87

2.9.1 Harmonics (Single-Tone Test) 87

2.9.2 Intermodulation Distortion (Two-Tone Test) 89

2.9.3 Receiver Performance Degradation due to the Non-linearities 92

2.9.4 Impact of Third-Order Nonlinearity in OFDM 95

2.9.5 Simulation in Complex Baseband 98

2.10 Power Amplifier Distortion 99

2.10.1 PA Modeling 99

2.10.2 Impact of PA Distortions in OFDM 102

References 104

3 Simulation of the RF Analog Impairments Impact on Real OFDM-Based Transceive

Product details

• Authors: L Smaini, Lydi Smaini, Lydi (Marvell Sarl) Smaini, Smaini Lydi
• Publisher: Wiley, John and Sons Ltd
• Languages: English
• Product format: Hardback
• Released: 01.09.2012
• EAN: 9781119999072
• ISBN: 978-1-119-99907-2
• No. of pages: 224
• Subjects: Natural sciences, medicine, IT, technology > Technology > Electronics, electrical engineering, communications engineering; Electrical & Electronics Engineering, Elektrotechnik u. Elektronik, Schaltkreise - Theorie u. Entwurf, Circuit Theory & Design, RF
