Informationen zum Autor LEI ZHU, PhD , is Associate Professor at the School of Electrical and Electronic Engineering, Nanyang Technological University, Singapore. Dr. Zhu was the first to introduce an MMR-based filter in 2000, which has since spurred the successful development of a new class of wideband filters with fractional bandwidths larger than 60 percent. SHENG SUN, PhD , is Research Assistant Professor in the Department of Electrical and Electronic Engineering at The University of Hong Kong. RUI LI, PhD, is a Research Fellow in the Interconnection and Advanced Packaging Program at Singapore's Institute of Microelectronics. She was the recipient of both the NTU Research and the Ministry of Education Scholarships in Singapore. Klappentext A Much-Needed Systematic Guide to the Design of (Ultra-)Wideband Bandpass Filters Ultra-wideband (UWB) technology has attracted a lot of attention in recent years, owing to its numerous applications in high-speed and high-capacity wireless communications. At the same time, conventional synthesis methodologies were shown to be inadequate for bandpass filtering design covering a wide or ultra-wide bandpass. This book responds to the need for a practical guide to emerging design techniques for advanced (ultra-)wideband bandpass filters. The authors introduce microwave wideband bandpass filter design theory using the multiple-mode resonator (MMR) along with the alternative synthesis design method for wideband bandpass filters, particularly for filters with FCC-defined UWB frequencies from 3.1 to 10.6 GHz. They demonstrate the application of both methods in the design of (ultra-)wideband bandpass filters, showing how to use these methods to implement filters in different frequencies and materials, calculate initial dimensions for various filter configurations, and more. Special features of this book include: Complete design procedures and tabulated design parameters for both MMR and the synthesis design method A large number of easy-to-follow design examples, which can be modified by readers to achieve their own design specifications Coverage of the basics, including transmission line theories and comparison with the design of conventional narrow-band bandpass filters Microwave Bandpass Filters for Wideband Communications is an invaluable guide for researchers and engineers wishing to improve their design cycle and filter performance. It is also a useful reference for newcomers to the field, who wish to gain a better understanding of (ultra-)wideband bandpass design theory. Zusammenfassung This book will appeal to scientists and engineers who are concerned with the design of microwave wideband devices and systems. For advanced (ultra)-wideband wireless systems, the necessity and design methodology of wideband filters will be discussed with reference to the inherent limitation in fractional bandwidth of classical bandpass filters. Inhaltsverzeichnis PREFACE ix 1 INTRODUCTION 1 1.1 Background on UWB Technology 2 1.2 UWB Regulations 3 1.3 UWB Bandpass Filters 8 1.4 Organization of the Book 11 2 TRANSMISSION LINE CONCEPTS AND NETWORKS 18 2.1 Introduction 18 2.2 Transmission Line Theory 19 2.3 Microwave Network Parameters 26 2.4 Relative Theories of Network Analysis 42 2.5 Summary 52 3 CONVENTIONAL PARALLEL-COUPLED LINE FILTER 53 3.1 Introduction 53 3.2 Lumped-Element Lowpass Filter Prototype 54 3.3 Impedance and Frequency Transformation 65 3.4 Immittance Inverters 70 3.5 Lowpass Prototype Filter with Immittance Inverter 71 3.6 Parallel-Coupled Line Bandpass Filter 76 3.7 Summary 84 4 PLANAR TRANSMISSION LINE RESONATORS 85 4.1 Introduction 85 4.2 Uniform Impedance Resonator ...
