The Herreshoff Sytsem of Motive Machinery

The distinguishing feature of the Herreshoff system of marine steam machinery, is the safety coil boiler, which has been brought to great perfection and patented by the Herreshoff Brothers. The boiler consists of a spiral coil made of iron tube arranged with proper spaces between the coils for the escape of the products of combustion. The coil is made of conical form and surrounds the combustion chamber, presenting an effective heating surface to the fire. The heated gases proceeding from this chamber are made to pass through the spaces of a flat coil at the top, which heats the feed water before its entrance to the boiler proper. The feed water is forced in at the cooler end of the flat coil, through which it passes to the top of the main coil, and descending, is finally discharged into a vertical cylinder, which is called the separator, and in which the steam and water discharged from the coil are divided, the water falling to the bottom, the steam being taken from the top and passed through a super-heating coil located above the main coil, which completely dries and superheats the steam.

Product details

• Assisted by: Bureau of Steam Engineering (Editor), Burea of Steam Engineering (Editor), Bureau of Steam Engineering (Editor)
• Publisher: Maritimepress
• Languages: English
• Product format: Paperback / Softback
• Released: 31.10.2015
• EAN: 9783954274918
• ISBN: 978-3-95427-491-8
• No. of pages: 84
• Dimensions: 148 mm x 210 mm x 5 mm
• Weight: 134 g
• Subject: Guides > Motor vehicles, aircraft, ships, space travel > Ships
