Informationen zum Autor Inder J. Bahl, PhD, has been working on microwave and millimeter wave GaAs ICs for more than twenty-five years. He is responsible for the design of over 400 MMICs, including low-noise amplifiers, driver amplifiers, broadband amplifiers, power amplifiers (high-power, high-efficiency, and broadband), dc and ac coupled transimpedance and limiting amplifiers, multi-bit phase shifters, narrow and broadband SPDT switches, redundant switches, programmable attenuators, balanced mixers, quadrature downconverters, upconverters, transmit chips, receive chips and transmit/receive chips. Dr. Bahl has also developed modules consisting of MMICs for PAR and ECM applications. Klappentext A Comprehensive and Up-to-Date Treatment of RF and Microwave Transistor AmplifiersThis book provides state-of-the-art coverage of RF and microwave transistor amplifiers, including low-noise, narrowband, broadband, linear, high-power, high-efficiency, and high-voltage. Topics covered include modeling, analysis, design, packaging, and thermal and fabrication considerations.Through a unique integration of theory and practice, readers will learn to solve amplifier-related design problems ranging from matching networks to biasing and stability. More than 240 problems are included to help readers test their basic amplifier and circuit design skills-and more than half of the problems feature fully worked-out solutions.With an emphasis on theory, design, and everyday applications, this book is geared toward students, teachers, scientists, and practicing engineers who are interested in broadening their knowledge of RF and microwave transistor amplifier circuit design. Zusammenfassung Includes extensive design information in the form of equations, tables, graphs and examples. Offers an in-depth study of amplifiers. Simple design equations are included to help understand design concepts. Practical and simple to understand examples with over 70 fully solved. Inhaltsverzeichnis Foreword. Preface. Chapter 1: Introduction. 1.1 Transistor Amplifier. 1.2 Early History of Transistor Amplifiers. 1.3 Benefits of Transistor Amplifiers. 1.4 Transistors. 1.5 Design of Amplifiers. 1.6 Amplifier Manufacturing Technologies. 1.7 Applications of Amplifiers. 1.8 Amplifier Cost. 1.9 Current Trends. 1.10 Book Organization. References. Chapter 2: Linear Network Analysis. 2.1 Impedance Matrix. 2.2 Admittance Matrix. 2.3 ABCD Parameters. 2.4 S-Parameters. 2.5 Relationships Between Various 2-Port Parameters. References. Problems. Chapter 3: Amplifier Characteristics and Definitions. 3.1 Bandwidth. 3.2 Power Gain. 3.3 Input and Output VSWR. 3.4 Output Power. 3.5 Power Added Efficiency. 3.6 Intermodulation Distortion. 3.7 Harmonic Power. 3.8 Peak-to-Average Ratio. 3.9 Combiner Efficiency. 3.10 Noise Characterization. 3.11 Dynamic Range. 3.12 Multi-Stage Amplifier Characteristics. 3.13 Gate and Drain Pushing Factors. 3.14 Amplifier Temperature Coefficient. 3.15 Mean Time To Failure. References. Problems. Chapter 4: Transistors. 4.1 Transistor Types. 4.2 Si Bipolar Transistor. 4.3 GaAs MESFET. 4.4 Hetrojunction Field Effect Transistor. 4.5 Hetrojunction BipolarTransistors. 4.6 MOSFET. References. Problems. Chapter 5: Transistor Models. 5.1 Transistor Model Types. 5.2 MESFET Models. 5.3 pHEMT Models. 5.4 HBT Model. 5.5 MOSFET Models. 5.6 BJT Models. 5.7 Transistor Model Scaling. 5.8 Source- and Load-Pull Data. 5.9 Temperature Dependent Models. References. Problems.
List of contents
Chapter 1: Introduction.
References.
Chapter 2: Linear Network Analysis.
References.
Problems.
Chapter 3: Amplifier Characteristics and Definitions.
References.
Problems.
Chapter 4: Transistors.
References.
Problems.
Chapter 5: Transistor Models.
References.
Problems.
Chapter 6: Matching Network Components.
References.
Problems.
Chapter 7: Impedance Matching Techniques.
References.
Problems.
Chapter 8: Amplifier Classes and Analyses.
References.
Problems.
Chapter 9: Amplifier Design Methods.
References.
Problems.
Chapter 10: High-Efficiency Amplifier Techniques.
References.
Problems.
Chapter 11: Broadband Amplifier Techniques.
References.
Problems.
Chapter 12: Linearization Techniques.
References.
Problems.
Chapter 13: High Voltage Power Amplifier Design.
References.
Problems.
Chapter 14: Hybrid Amplifiers.
References.
Problems.
Chapter 15: Monolithic Amplifiers.
References.
Problems.
Chapter 16: Thermal Design.
References.
Problems.
Chapter 17: Stability Analyses.
References.
Problems.
Chapter 18: Biasing Networks.
References.
Problems.
Chapter 19: Power Combining.
References.
Problems.
Chapter 20: Integrated Function Amplifiers.
References.
Problems.
Chapter 21: Amplifier Packages.
References.
Problems.
Chapter 22: Transistor and Amplifier Measurements.
References.
Problems.
Appendices.
Appendix A: Physical Constants and Other Data.
Appendix B: Units and Symbols.
Appendix C: Frequency Band Designation.
Appendix D: Decibel Units - DB.
Appendix E: Mathematical Relations.
Appendix F: Smith Chart.
Appendix G: Graphical Symbols.
Appendix H: Acronyms and Abbreviations.
Appendix I: List Of Symbols.
Appendix J: Multiple Access and Modulation Techniques.
