Noise-Shaping All-Digital Phase-Locked Loops

This book presents a novel approach to the analysis and design of all-digital phase-locked loops (ADPLLs), technology widely used in wireless communication devices. The authors provide an overview of ADPLL architectures, time-to-digital converters (TDCs) and noise shaping. Realistic examples illustrate how to analyze and simulate phase noise in the presence of sigma-delta modulation and time-to-digital conversion. Readers will gain a deep understanding of ADPLLs and the central role played by noise-shaping. A range of ADPLL and TDC architectures are presented in unified manner. Analytical and simulation tools are discussed in detail. Matlab code is included that can be reused to design, simulate and analyze the ADPLL architectures that are presented in the book.

Inhaltsverzeichnis

Introduction.- Phase Digitization in All-Digital PLLs.- A Unifying Framework for TDC Architectures.- Analytical Predictions of Phase Noise in ADPLLs.- Advantages of Noise Shaping and Dither.- Efficient Modeling and Simulation of Accumulator-Based ADPLLs.- Modelling and Estimating Phase Noise with Matlab.

Zusammenfassung

This book presents a novel approach to the analysis and design of all-digital phase-locked loops (ADPLLs), technology widely used in wireless communication devices. The authors provide an overview of ADPLL architectures, time-to-digital converters (TDCs) and noise shaping. Realistic examples illustrate how to analyze and simulate phase noise in the presence of sigma-delta modulation and time-to-digital conversion. Readers will gain a deep understanding of ADPLLs and the central role played by noise-shaping. A range of ADPLL and TDC architectures are presented in unified manner. Analytical and simulation tools are discussed in detail. Matlab code is included that can be reused to design, simulate and analyze the ADPLL architectures that are presented in the book.

Produktdetails

• Autoren: Francesc Brandonisio, Francesco Brandonisio, Michael Peter Kennedy
• Verlag: Springer, Berlin
• Sprache: Englisch
• Produktform: Fester Einband
• Erschienen: 04.11.2013
• EAN: 9783319036588
• ISBN: 978-3-31-903658-8
• Seiten: 177
• Abmessung: 170 mm x 245 mm x 16 mm
• Gewicht: 403 g
• Illustration: XIII, 177 p. 145 illus., 79 illus. in color.
• Serien: Analog Circuits and Signal Processing; Analog Circuits and Signal Processing
• Themen: Naturwissenschaften, Medizin, Informatik, Technik > Technik > Elektronik, Elektrotechnik, Nachrichtentechnik; B, engineering, Signal, Image and Speech Processing, Circuits and Systems, Signal Processing, Electronics, Microelectronics, Electronics and Microelectronics, Instrumentation, Speech processing systems, Imaging systems & technology, Image processing, Electronics engineering, Electronic circuits, Electronic Circuits and Systems, Signal, Speech and Image Processing
